Connectors
|
INPUT jack: 1/4-inch phone type, POWER AMP IN jack: 1/4-inch phone type, BALANCED OUT jack: 1/4-inch phone type, SEND jack: 1/4-inch phone type, RETURN jack: 1/4-inch phone type, REC OUT/PHONES jack: Stereo 1/4-inch phone type, EXP PEDAL/CTL CH1/CH2 jack: 1/4-inch TRS phone type, GA-FC jack: 1/4-inch TRS phone type, AUX IN jack: Stereo miniature phone type, USB port: USB B type, BLUETOOTH ADAPTOR SLOT: BluetoothⓇ Audio MIDI Dual Adaptor, AC IN jack
|
|
Controls
|
POWER switch, MASTER VOLUME knob, POWER CONTROL switch (STANDBY, 1 W, MAX), TWEETER button, [INPUT EFX], COMP button, DRIVE button, COMP knob, DRIVE knob, [AMPLIFIER], PAD button, SHAPE button, TYPE knob (VINTAGE, FLAT, MODERN), GAIN knob, VOLUME knob, [BLEND], BLEND button, DRY LEVEL knob, [EQUALIZER], LOW MID button, HIGH MID button, BASS knob, LOW MID knob, HIGH MID knob, TREBLE knob, [EFFECTS], FX1 button, FX2 button, TAP button, FX1 knob, FX2 knob, [TONE SETTING], CH1 button, CH2 button, CH3 button, PANEL button, [BALANCED OUT], GND LIFT switch (OFF, ON), SELECT (POST, PRE, DIRECT)
|
|
Depth
|
11-13/16 inches
|
|
Height
|
19-11/16 inches
|
|
Indicator
|
COMP, DRIVE, PAD, SHAPE, BLEND, LOW MID, HIGH MID, FX1, FX2, TAP, CH1, CH2, CH3, PANEL, TWEETER
|
|
Nominal Input Level
|
INPUT: -10 dBu (1 M ohm), POWER AMP IN: -10 dBu (20 k ohms), AUX IN: -10 dBu (20 k ohms), RETURN IN: -10 dBu (100 k ohm)
|
|
Options (sold separately)
|
Footswitch: BOSS FS-5L, BOSS FS-6, BOSS FS-7, Expression pedal: Roland EV-5, BOSS EV-30, BOSS FV-500L, BOSS FV-500H, GA FOOT CONTROLLER (GA-FC), BluetoothⓇ Audio MIDI Dual Adaptor (Model BT-DUAL) (sold separately)
|
|
Power Consumption
|
77 W
|
|
Speakers
|
WOOFER: 25 cm (10 inches) x 1, TWEETER: x 1
|
|
Type
|
Bass Amplifier
|
|
Weight
|
37 lbs 0.6 oz
|
|
Width
|
18-9/16 inches
|
